Stability Improvements in a Rail-to-Rail Input/Output, Constant Gm Operational Amplifier, at 0.4 V Operation, Using the Low-Voltage DTMOS Technique - Technological Innovation for Collective Awareness Systems (DoCEIS 2014)
Conference Papers Year : 2014

Stability Improvements in a Rail-to-Rail Input/Output, Constant Gm Operational Amplifier, at 0.4 V Operation, Using the Low-Voltage DTMOS Technique

Abstract

The use of the dynamic threshold MOS (DTMOS) technique is evaluated in a two-stage rail-to-rail Input/Output, constant Gm amplifier. The proper choice of specific transistors in which the technique should be used is presented, as well as the resulting improvements, mainly regarding stability of the circuit at low voltage operation. The DTMOS technique is used in the NMOS transistors of the folded-cascode input stage, allowing the circuit to be stable at VDD = 0.4 V, with equivalent gain and gain-and-bandwidth product (GBW) values achieved with the same VDD value, for the initial circuit operating at 0.8 V. The implemented changes allow the circuit to be stable at low voltage operations without requiring any increase in the cascoded-Miller compensation capacitors, saving circuit area and, consequently, cost.
Fichier principal
Vignette du fichier
978-3-642-54734-8_65_Chapter.pdf (166.95 Ko) Télécharger le fichier
Origin Files produced by the author(s)
Loading...

Dates and versions

hal-01274826 , version 1 (16-02-2016)

Licence

Identifiers

Cite

Joana Correia, Nuno Mancelos, João Goes. Stability Improvements in a Rail-to-Rail Input/Output, Constant Gm Operational Amplifier, at 0.4 V Operation, Using the Low-Voltage DTMOS Technique. 5th Doctoral Conference on Computing, Electrical and Industrial Systems (DoCEIS), Apr 2014, Costa de Caparica, Portugal. pp.585-591, ⟨10.1007/978-3-642-54734-8_65⟩. ⟨hal-01274826⟩
