Robust Optimization-Based High Frequency Gm-C Filter Design

Abstract

An optimization-based methodology for designing robust high frequency Gm-C filters is presented. In the first step of the design, the topology for high-frequency Gm-C filter is obtained directly from an active RC prototype, using the a transformation method proposed in [1]. where a transformation method for designing Gm-C filters from known RC filters while grounding floating capacitors is proposed. In the above mentioned paper the filter elements values are obtained by a user-defined methodology which can produce high sensitivity to component variations. In the work developed, the analytical characterization of a 2nd order Gm-C Sallen-Key LP filter is considered as well as the corresponding symbolic expressions for their sensitivity to component value variations. By using the minimization of the sensitivity as a goal function in the optimization process, parasitic capacitances are canceled and robust designs are obtained. Optimization and simulations results that validate the theoretical results are presented.
Fichier principal
Vignette du fichier
978-3-642-28255-3_51_Chapter.pdf (114.77 Ko) Télécharger le fichier
Origin Files produced by the author(s)
Loading...

Dates and versions

hal-01365760 , version 1 (13-09-2016)

Licence

Identifiers

Cite

Pedro Vicente Leitão, Helena Fino. Robust Optimization-Based High Frequency Gm-C Filter Design. 3rd Doctoral Conference on Computing, Electrical and Industrial Systems (DoCEIS), Feb 2012, Costa de Caparica, Portugal. pp.465-474, ⟨10.1007/978-3-642-28255-3_51⟩. ⟨hal-01365760⟩
