Dual-Stage Feed Drive for Precision Positioning on Milling Machine

Abstract

A positioning system with long stroke and high precision by dual-stage control was designed. The focus was on combining the long-stroke travel range of linear stage with high-precision characteristics of piezoelectric actuators. The control method used in the system was dynamic compensation type, where the error from linear stage becomes the input to the piezoelectric actuators. Positioning error of 30 μm with single-stage control in a 1 mm stroke can be reduced to 2 μm by using dual-stage control. This technique can be implemented for high-precision positioning in manufacturing and machining systems.
Fichier principal
Vignette du fichier
978-3-642-28163-1_11_Chapter.pdf (459.77 Ko) Télécharger le fichier
Origin Files produced by the author(s)
Loading...

Dates and versions

hal-01363886 , version 1 (12-09-2016)

Licence

Identifiers

Cite

Hendra Prima Syahputra, Hyeon Mo Yang, Byeong Mook Chung, Tae Jo Ko. Dual-Stage Feed Drive for Precision Positioning on Milling Machine. 6th International Precision Assembly Seminar (IPAS), Feb 2012, Chamonix, France. pp.81-88, ⟨10.1007/978-3-642-28163-1_11⟩. ⟨hal-01363886⟩
