Packaging is one of the major cost drivers for MEMS devices. Currently wire bonding is the dominant method for electrically connecting MEMS chips to substrate. Using self-alignment a method for packaging multiple MEMS at the same time has been developed. The presented process achieves high throughput and precise alignment at low cost. The Controlled Collapse Re-flow Chip Joining (C-4) process has been adapted to the specific requirements of MEMS. The combination of coarse robotics and liquid solder self-alignment guarantees precise positioning and alignment of the individual MEMS chips to the respective substrates. The new method has been implemented in a case study. In the study force sensors have been packaged. Precise angular alignment of the sensors is critical for receiving accurate measurements. Results of the case study are presented.
